Features

01/

Unique labyrinth shaft-end sealing structure ensures that dust and product particles cannot enter the main bearings or motor bearings, significantly extending service life.

02/

Elastic counterweight support device is installed at the lower section of the main shaft to improve balance and operational stability.

03/

Precision self-aligning roller bearings are used on the drive shaft, ensuring accurate concentric rotation and smooth performance.

04/

Simple and convenient sieve frame clamping mechanism allows easy operation. Various clamping options are available, including vertical clamping, side clamping, and pneumatic clamping.

05/

The Square Plansifter's innovative sieve box design increases effective screening area and improves processing capacity.

06/

Strict sealing of sieve doors and product passages prevents material leakage and cross-contamination between passages.

07/

The Square Plansifter features a fully enclosed machine structure that provides an attractive appearance and clean operation. The surface is treated with an electrostatic powder coating process for enhanced durability.

08/

The Square Plansifter's heavy-duty machine body construction utilizes high-fatigue-strength automotive chassis steel from Baosteel, while all material-contact parts are made of food-grade stainless steel.

09/

Embedded support-free sieve frames with die-cast aluminum sieve cores ensure durability, precision, and easy maintenance.

10/

Drive mechanism with triple-spring core support design balances axial loads on the upper and lower bearings, improving reliability and bearing life.

11/

Dual sealing protection system, combining labyrinth seals and oil seals, effectively prevents external dust from entering the bearing assemblies.

Model	Bins	Max Sieve Box QTY	Max Sieve Area ㎡	Main Shaft Speed rpm	Diameter Of Gyration mm	Effective Sieve Height mm	Top Sieve Height mm	Power kw	Weight kg
FSFG 640×2×27	2	24	14.3	245	64±0.5	1890-1920	140	3	2400
FSFG 640×4×27	4	24	28.7	245	64±0.5	1890-1920	140	3	3250
FSFG 640×6×27	6	24	43.0	245	64±0.5	1890-1920	140	5.5	4250
FSFG 640×8×27	8	24	57.4	245	64±0.5	1890-1920	140	7.5	5680

Model	Bins	Max Sieve Box QTY	Max Sieve Area ㎡	Main Shaft Speed rpm	Diameter Of Gyration mm	Effective Sieve Height mm	Top Sieve Height mm	Power kw	Weight kg
FSFG(B)640×4×27	4	27	32.3	245	64±0.5	1890-1920	140	3	3350
FSFG(B)640×6×27	6	27	48.4	245	64±0.5	1890-1920	140	5.5	4350
FSFG(B)640×8×27	8	27	64.6	245	64±0.5	1890-1920	140	7.5	5800

Model	Bins	Max Sieve Box QTY	Max Sieve Area ㎡	Main Shaft Speed rpm	Diameter Of Gyration mm	Effective Sieve Height mm	Top Sieve Height mm	Power kw	Weight kg
FSFG 740×4×27	4	24	36.7	245	64±0.5	1890-1920	140	5.5	3900
FSFG 740×6×27	6	24	55.2	245	64±0.5	1890-1920	140	7.5	4850
FSFG 740×8×27	8	24	73.5	245	64±0.5	1890-1920	140	15	6080

Model	Bins	Max Sieve Box QTY	Max Sieve Area ㎡	Main Shaft Speed rpm	Diameter Of Gyration mm	Effective Sieve Height mm	Top Sieve Height mm	Power kw	Weight kg
FSFG (B)740×4×27	4	27	41.3	245	64±0.5	1890-1920	140	5.5	4000
FSFG (B)740×6×27	6	27	62.1	245	64±0.5	1890-1920	140	7.5	4950
FSFG (B)740×8×27	8	27	82.7	245	64±0.5	1890-1920	140	15	6200
