Application
The equipment is used for crushing hard and non-uniform particles (1–20 mm), as well as chemical raw materials and similar materials in size-reduction processes.
Features
The twin roll grain cracker are made of nickel-chromium-molybdenum alloy for high wear resistance and durability.
Bearings are SKF, ensuring reliable and stable operation. Pulley system uses Deen Precision Engineering components, and belts are from Sanlux.
All material-contact parts are made of 304 stainless steel to meet hygienic and corrosion-resistant requirements.
The base frame is fabricated from high-quality carbon structural steel through welding, providing strong rigidity and stability.
The control system adopts Siemens PLC combined with internationally recognized electrical components, ensuring high automation and reliability.
| Drive Configuration |
twin roll grain cracker are driven by a single motor, while the feed rolls and leveling rolls are driven by two independent motors. |
Total Machine Weight | 6 tons. | |||
| Motor Power |
twin roll grain cracker motor 37 kW; feed roller and leveling roller motors 0.75 kW × 2. |
Overall Dimensions |
2710 × 1340 × 1820 mm (excluding main motor installation space). |
|||
| Grinding Roll Size |
φ400 × 1500 mm. |
|
|
|||
