Application

The pulse jet baghouse is widely used for dust filtration and material recovery in industries such as grain and oil processing, food production, light industry, chemical engineering, mining, cement, and woodworking.

Features

01/

The pulse jet baghouse utilizes high-pressure pulse jet cleaning for efficient dust removal and stable filtration performance.

02/

Cylindrical structure with flat-bottom scraper discharge ensures smooth and reliable material unloading.

03/

Centrifugal tangential air inlet design reduces energy consumption and improves separation efficiency.

04/

Compact design with reduced installation height, saving plant space.

05/

The pulse jet baghouse Simple operation and easy maintenance, suitable for continuous industrial use.

Model	BLM-26			BLM-39			BLM-52
Parameter	b	a	c	b	a	c	b	a	c
Filter Area ㎡	17.6	19.6	23.5	26.4	29.4	35.3	35.3	39.2	47
Bag QTY	26			39			52
Bag Length mm	1800	2000	2400	1800	2000	2400	1800	2000	2400
Filter Air Volume m³/h	3170-4220	3530-4700	4230-5640	4750-6340	5290-7060	6350-8470	6350-8470	7060-9410	8460-11280
Weight kg	1030	1070	1120	1200	1240	1290	1390	1410	1460
Air Consumption m³/min	0.15			0.17			0.2
Power kw	1.5			1.5			1.5

Model	BLM-78			BLM-104			BLM-130			BLM-156
Parameter	b	a	c	b	a	c	b	a	c	b	a	c
Filter Area ㎡	52.9	58.8	70.5	70.5	78.4	94	88.1	98	117.5	105.8	117.6	141
Bag QTY	78			104			130			156
Bag Length mm	1800	2000	2400	1800	2000	2400	1800	2000	2400	1800	2000	2400
Filter Air Volume m³/h	9520-12700	10580-14110	12600-16920	12690-16920	14100-18810	16920-22560	15860-21140	17440-23520	21150-28200	19040-25390	21170-28220	25380-33840
Weight kg	1840	1880	1930	2280	2320	2370	2390	2990	3080	3360	3450	3550
Air Consumption m³/min	0.22			0.28			0.4			0.6
Power kw	1.5			1.5			1.5			2.2+1.5+1.5
